M12 / LS12J / LSP27B2 / LSP32B2 / LSP37B2

Log Splitter

POA

Find a dealer Dealer Login

Our extensive range of manual and powered Professional log splitters are designed to split gnarly wood chunks, branch crotches, end cuts and firewood logs with ease, ensuring maximum efficiency and increased productivity.

With options ranging from compact manual splitters through to powerful 27T, 32T and 37T petrol-powered units, the COX Log Splitter range provides smooth operation, rugged construction and dependable performance for home, lifestyle and commercial users.

Key Features

Flip-up forward stand with spring-loaded lock for quick positioning and storage.
Auto-return valve on 27T, 32T and 37T models for faster splitting cycles.
Built-in log cradle for safer operation and easier log handling (27T, 32T, 37T).
Pneumatic tyres for improved stability and easy manoeuvring over rough ground.
Standard 50mm tow hitch included on 27T, 32T and 37T models.
Vertical and horizontal operation on 27T, 32T and 37T models for ultimate flexibility.
Powerful Briggs & Stratton engines available across the range for dependable splitting performance.
Designed to tackle tough Australian hardwoods, knotty logs and dense timber.
Heavy-duty beam and steel construction ensuring long-term durability.
Fast cycle times for increased splitting efficiency.

Specifications

Models
Model Options

M12, LS12J, LSP27B2, LSP32B2, LSP37B2
Engine
Engine

M12: Manual, LS12J: COX 6.5hp, LSP27B2: B&S 6.5hp, LSP32B2: B&S 7.5hp, LSP37B2: B&S 10hp
Splitting Force
Ton Rating

M12: 12 Ton, LS12J: 12 Ton, LSP27B2: 27 Ton, LSP32B2: 32 Ton, LSP37B2: 37 Ton
Capacity
Max Log Length

M12: 400mm, LS12J: 508mm, LSP27B2: 660mm, LSP32B2: 660mm, LSP37B2: 660mm
Max Log Diameter

M12: 300mm, LS12J: 400mm, LSP27B2: 400mm, LSP32B2: 400mm, LSP37B2: 400mm
Performance
Cycle Time

M12: Manual, LS12J: 13.3 Sec, LSP27B2: 13.5 Sec, LSP32B2: 14 Sec, LSP37B2: 14 Sec
Hydraulics
Hydraulic Capacity

M12: N/A, LS12J: 8 Litres, LSP27B2: 24 Litres, LSP32B2: 30 Litres, LSP37B2: 33 Litres
Hydraulic System

M12: Suction, LS12J: Suction, LSP27B2: Auto-Return, LSP32B2: Auto-Return, LSP37B2: Auto-Return
Wedge & Operation
Wedge Size

M12: 150mm, LS12J: 160mm, LSP27B2: 228mm, LSP32B2: 228mm, LSP37B2: 254mm
Orientation

Vertical/Horizontal on 27T, 32T, 37T; Manual on M12 & LS12J
Hitch & Tow
Tow Hitch

M12: None, LS12J: None, LSP27B2: 50mm, LSP32B2: 50mm, LSP37B2: 50mm
Wheels
Wheel Type

M12: Pneumatic, LS12J: Pneumatic, LSP27B2: Pneumatic, LSP32B2: Pneumatic, LSP37B2: Pneumatic
Weights
Weight

M12: 53kg, LS12J: 110kg, LSP27B2: 236kg, LSP32B2: 240kg, LSP37B2: 293kg
Warranty
Warranty

2 Years*
